Graham Audio - LS 6f Rosewood

Hersteller: Graham Audio
Art.Nr.: GRA-000304555-HAM
Lieferzeit: 5-7 Tage
Graham Audio - LS 6f Rosewood
3.800,00 EUR
inkl. 19 % MwSt. zzgl. Versandkosten
Menge:

The Chartwell LS6/f

Building on the success of our popular LS6 monitor, the LS6/f is a floor-standing loudspeaker system that combines a modern aesthetic with the open, uncoloured sound you'd expect from a Graham Audio system.

The integrated plinth provides a flow-optimised path for the airflow from the port, reducing distortion at high outputs.

The LS6/f uses the same custom drive units as the stand-mount LS6 and has an optimised crossover network using premium quality components to integrate the acoustic output from both drive units and equalise the overall response for optimum performance in free space. A switch on the front panel adds 1 or 2dB to the tweeter level, which might be advantageous in certain acoustic environments.



In common with all our loudspeakers, the cabinet uses the classic BBC "thinwall" construction, where the panels are mass-loaded to ensure that resonances are moved away from the critical mid-range region, and a layer of Rockwool is held in place by fabric to provide air damping. Hand-matched veneers are applied and finished to a very high standard. The grille is carefully designed to minimise diffraction effects and is held in place by concealed rare-earth magnets.

Specifications

System 2 Way, reflex loading
Enclosure Thin wall damped construction
Finish Real wood veneer
Dimensions (w/h/d) 96cm by 32cm by 32cm (including plinth)
Weight 21kg
Frequency response 40Hz to 20kHz, ±2dB
Nominal impedance
Sensitivity 87dB SPL (2.83V, 1m)
Maximum output Over 100dB for a pair at 2m
Bass/midrange 165mm Polypropylene
Tweeter 19mm Dome tweeter
Recommended amplifier power 50 to 150 watts unclipped programme

Bilder dienen nur zur veranschaulichung, das Endprodukt kann vom Bild abweichen

Diesen Artikel haben wir am Dienstag, 04. Dezember 2018 in unseren Katalog aufgenommen.
